150lm W High Power LED High Mast Light TEIJIN PC Lens Stadium Lighting
| Material | Aluminum |
| Lens Material | Japan TEIJIN PC Lens |
| Max Wattage | 1500W High Power |
Talk to Our Engineer Now 1. ADC12 Die-Casting Heat Sink
The fixture utilizes an ADC12 Aluminum Die-casting housing which provides excellent thermal management and a highly compact structure. An integrated breather valve balances internal and external temperature and humidity, preventing condensation and protecting internal electronics.
2. TEIJIN PC Lens & 150lm/W Efficacy
The optical engine is built with Japan brand TEIJIN polycarbonate lenses, renowned for their anti-UV properties and high mechanical strength. Paired with LUMILEDS or OSRAM chips, the system achieves a luminous efficacy of 150lm/W ±5%, offering massive energy savings for high mast projects.
3. Spill Visor & Asymmetrical Beams
To meet strict environmental regulations, the light is equipped with visor options that effectively control spill and upward light, avoiding lighting pollution. It supports a wide range of beam angles including 10°, 15°, 25°, 45°, 60°, 90°, and asymmetrical 60° options to suit any arena layout.
4. WF2 Treatment & Tempered Glass
The high-strength cold-rolled plate brackets receive a special corrosion treatment to reach the WF2 standard, making them highly suitable for harsh environments. Furthermore, an optional 4mm high-strength tempered glass cover is available to further reduce UV degradation and rust, typically designed for coastal areas.
| Product Series | SPORTLUX™ ADC12 Die-Casting Series |
| Wattage Range | 250W, 500W, 750W, 1000W, 1250W, 1500W |
| Luminous Efficacy | 150lm/W ±5% |
| Housing Material | ADC12 Aluminum Die-casting |
| Lens Material | Japan brand TEIJIN PC Lens / Optional 4mm Tempered Glass |
| LED Chips | LUMILEDS / OSRAM (3737 & 2835 options) |
| Driver Brand | Meanwell / Sosen |
| Anti-Corrosion Standard | WF2 Standard |
| Beam Angle | 10°/15°/25°/45°/60°/90° & Asymmetrical 60° |
| Angle Adjustment | 10° steps, up to 270° installation adjustment |
Ideal Applications for High Power Floodlights
Engineered to deliver up to 1500W of precision illumination, this fixture is designed for demanding outdoor and industrial sectors.
Coastal Terminals & Seaports
Marine environments require exceptional durability. With the WF2 Anti-Corrosion Treatment and an optional 4mm Tempered Glass Cover, this light heavily resists UV degradation and salt-spray rust common in harbor projects.
Large Sports Stadiums
For venues requiring HDTV broadcasting standards, the Spill Visor eliminates upward light trespass. The TEIJIN PC Lens combined with asymmetrical beams directs the 150lm/W output exactly onto the field, improving uniformity and reducing glare for athletes.
High Mast Area Lighting
Replacing 3000W HID lamps on 30+ meter poles requires extreme power. The 1500W configuration provides massive lumen output for airport aprons, rail yards, and mining sites. The 270° racked angle adjustment makes precise aiming easy during installation.
