Home / Products / 3-5M Modern Geometric LED Landscape Light 30W Galvanized Steel Decorative Post with Acrylic Shade

3-5M Modern Geometric LED Landscape Light 30W Galvanized Steel Decorative Post with Acrylic Shade

Model: DL01-A03A03-003 Landscape lighting should complement the architecture it surrounds. The DL01-A03A03-003 landscape light stands out with its distinctive, stacked geometric top design, acting as a modern sculpture during the day and a reliable pedestrian light at night. Available in highly customizable heights from 3 to 5 meters, it is fabricated from heavy-duty galvanized steel to prevent base rust. The fixture utilizes an anti-glare acrylic lampshade that softens the high-efficiency 30W LED output (120lm/W), providing a safe, comfortable glow for pathways and plazas. Fully IP65 weatherproofed and capable of handling extreme temperatures (-20°C to 60°C), it is a practical and aesthetic lighting solution backed by a 3-5 year warranty.

Power & Source	30W LED (120lm/W)
IP Rating	IP65 Outdoor Rated
Warranty	3-5 Years

View Features

Data Sheet:

DL01-A03A03-003_compressed.pdf

Talk to Our Engineer Now

*Motor detailed config can be customized according to customer's requests, like voltage, speed, as well as shaft length and shape...

Features

Specifications

Applications

Features

1. Distinctive Geometric Top Design

Visual identity matters in high-end developments. This fixture features a unique, layered architectural top crafted from 1.2mm galvanized steel plates. This modern, industrial-inspired look perfectly complements contemporary commercial buildings, corporate campuses, and minimalist hardscaping.

2. Pedestrian-Friendly Anti-Glare Lighting

In walking zones, exposed LEDs create blinding glare. We utilize a premium frosted acrylic lampshade that diffuses the 30W light source into a wide, even spread. It delivers functional security lighting for pathways without causing eye fatigue for pedestrians and cyclists.

3. Project-Specific Scaling (3-5M Heights)

You aren’t locked into a single size. We manufacture this pole in variable heights from 3 meters (ideal for intimate courtyard paths) up to 5 meters (perfect for illuminating wider open plazas). This allows you to maintain a consistent design language across different areas of your project.

4. Outdoor-Ready Durability (Galvanized & IP65)

Landscape lights face constant exposure to lawn sprinklers, rain, and soil moisture. The main body is constructed from galvanized steel to actively prevent rust at the ground level. With an IP65 rating, the internal LED and driver are fully protected against heavy water jets and dust ingress.

Specifications

Model Number	DL01-A03A03-003
Pole Height Options	3M – 5M (Customizable)
Power Consumption	30W
Light Source & Efficacy	LED, 120 lm/W
Input Voltage	AC 85-265V
Color Temp (CCT) & CRI	3000K – 6000K, Ra > 80
Housing Material	Galvanized Steel Body + Acrylic Lampshade
Top Cap Detail	1.2mm Galvanized Steel Plate Assembly
IP Rating	IP65 (Outdoor Waterproof)
Working Temperature	-20°C to +60°C
Lifespan & Warranty	50,000 Hours / 3-5 Years Warranty

Applications

Where Does This Geometric Landscape Light Make Sense?

Thanks to its distinctive stacked top design and soft acrylic illumination, this fixture is the perfect tool for landscape architects aiming to match modern, industrial, or minimalist outdoor environments.

Corporate Campuses & Tech Hubs

Modern office parks demand lighting that feels intentional. The geometric steel layering of this pole aligns perfectly with the sharp lines of modern glass-and-steel headquarters, providing safe pathway lighting for employees working late.

Urban Commercial Plazas

When set to a 5-meter height, these poles act as architectural markers for shopping districts. The anti-glare 30W LED provides excellent ground visibility without blinding shoppers, creating a comfortable retail atmosphere.

Modern Park Promenades

For newly developed city parks or riverfront walkways, the IP65 galvanized steel body ensures the fixture easily handles sprinkler water, heavy rain, and public wear-and-tear while delivering a highly aesthetic silhouette during daylight hours.
