50W Outdoor LED Flood Light IP66 Waterproof COB Security Fixture for Building Facades

Model: DL01-A07A10-001 Outdoor flood lighting requires fixtures that can handle severe heat, heavy rain, and electrical fluctuations. The DL01-A07A10-001 is a professional-grade 50W LED flood light built around a thickened die-cast aluminum housing. It utilizes high-penetration Epistar COB chips that deliver up to 100lm/W of focused illumination. To ensure long-term stability in harsh environments, it is sealed to a strict IP66 waterproof rating and equipped with built-in Surge Protection Devices (SPD) ranging from 2.5KV up to 10KV. Powered by Tier-1 drivers like Meanwell or Inventronics, this fixture guarantees a 50,000-hour lifespan without flickering or premature light decay, making it the perfect choice for building facades, billboards, and security perimeters.

Driver	Meanwell / Inventronics / Dawn (CE-EMC)
IP Rating	IP66 Waterproof
Material	Die-cast Aluminum + Tempered Glass

View Features

Data Sheet:

Talk to Our Engineer Now

*Motor detailed config can be customized according to customer's requests, like voltage, speed, as well as shaft length and shape...

Features

Specifications

Applications

Features

1. Advanced Thermal Management

Heat is the number one killer of LEDs. We don’t use thin, stamped metal. This fixture uses a thickened die-cast aluminum housing with deep striped heat sinks on the back. This design pulls heat away from the COB chip rapidly, ensuring low light decay and maintaining high brightness over its 50,000-hour lifespan.

2. Premium Epistar COB Engine

Instead of scattered SMD chips, this model features a concentrated Chip-on-Board (COB) LED from Epistar. COB technology provides a denser, highly uniform beam with superior center-beam candlepower (CBCP). This makes it exceptional for spotting specific architectural details or washing large billboards with consistent light.

3. Tier-1 Drivers & Extreme Surge Protection

Outdoor fixtures are highly vulnerable to lightning strikes and grid voltage spikes. To prevent premature driver failure, we offer Tier-1 power supplies (Meanwell or Inventronics), paired with optional Surge Protection Devices (SPD) capable of absorbing hits from 2.5KV up to a massive 10KV.

4. IP66 Dust & Waterproof Rating

Engineered for the harshest environments. The tempered glass face and silicone gaskets are tightly sealed into the aluminum body, achieving a strict IP66 rating. It is completely protected against dust ingress and can easily withstand high-pressure water jets during severe storms.

Specifications

Model Number	DL01-A07A10-001
Power Consumption	50W
LED Chip Type	COB (Epistar)
Luminous Efficacy	80-85 LM/W ; 90-100 LM/W Options
Driver Options	Meanwell / Inventronics / Dawn (CE-EMC)
Input Voltage	AC85-305V / AC165-277V
Power Factor (PF) & Ra	PF > 0.90 / Ra 70
Surge Protection (SPD)	2.5KV / 4KV / 6KV / 10KV Options
Housing Material	Die-cast Aluminium + Glass, AL diffuser
IP Rating	IP66 (Dustproof & Waterproof)
Installation Type	Adjustable U-Bracket
Lifespan & Warranty	50,000 Hours / 3-5 Years Warranty

Applications

这款50W COB泛光灯有哪些优势？

50W的输出功率结合COB芯片的聚焦光束，使这款灯具用途广泛。它能提供强劲而精准的光线，适用于商业广告和建筑装饰。

广告牌和标牌照明

COB芯片可提供强劲均匀的光线，避免了标准SMD芯片常见的“多重阴影”效应。可调节支架能够实现精准瞄准，完美照亮大型户外广告牌。

建筑立面与景观

建筑师使用这款 50 瓦的灯具来照亮建筑外墙、历史古迹或大型树木。其 IP66 防护等级确保它能够承受地面潮湿环境和园林绿化中的自动喷灌系统。

安防及周边照明

可安装在工厂周边、仓库或住宅后院的墙壁或杆子上。坚固耐用的铝制外壳和10KV浪涌保护功能确保即使在强雷暴天气下也能提供可靠的安防照明。
